19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications

19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications

Large Image :  19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications

Product Details:
Place of Origin: Shandong, China
Brand Name: HONGKANG
Payment & Shipping Terms:
Minimum Order Quantity: A production line
Price: $150,000.00/sets 1-1 sets
Packaging Details: Container
Delivery Time: 1 line for 3 months
Payment Terms: L/C TT
Supply Ability: 1 line for 3 months
Contact Now

19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications

Description
Table Size (mm): 900*1300 Table Travel (X) (mm): 1800 Mm
Table Travel (Y) (mm): 1200 Mm Table Travel (Z) (mm): 700 Mm
Number Of Axes: 4 Max. Table Load(kg): 5T
Travel (W-axis) (mm): 600 Mm Video Outgoing-inspection: Provided
Machinery Test Report: Not Available Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year Core Components: PLC, Bearing, Gearbox, Motor, Gear, Pump
Positioning Accuracy (X Axis) Mm: 0.04 Positioning Accuracy (Y Axis) Mm: 0.04
Positioning Accuracy (Z Axis) Mm: 0.032 No. Of Spindles: 4
Range Of Spindle Speed(r.p.m): 950 R.p.m Spindle Motor Power(kW): 16
Type: VERTICAL Condition: New
CNC Or Not: CNC Voltage: 380V
Dimension(L*W*H): 4800*5000*4800mm Weight (T): 19 T
Warranty: 1 Year Key Selling Points: High Productivity
Applicable Industries: Manufacturing Plant, Energy & Mining, Other Showroom Location: None
Product Name: Boring Machine Tool After-sales Service Provided: One Year
Port: Qingdao Port

Product Description
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 0
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 1
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 2
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 3
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 4
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 5
Specification
item
value
Table Size (mm)
900*1300
Table Travel (X) (mm)
1800mm
Table Travel (Y) (mm)
1200mm
Table Travel (Z) (mm)
700mm
Number of Axes
4
Max. Table Load(kg)
5T
Travel (W-axis) (mm)
600mm
Video outgoing-inspection
Provided
Machinery Test Report
Not Available
Marketing Type
New Product 2020
Warranty of core components
1 Year
Core Components
PLC, Bearing, Gearbox, Motor, Gear, Pump
Positioning Accuracy (X axis) mm
0.04
Positioning Accuracy (Y axis) mm
0.04
Positioning Accuracy (Z axis) mm
0.032
No. of Spindles
4
Range of Spindle Speed(r.p.m)
950r.p.m
Spindle Motor Power(kW)
16
Type
VERTICAL
Condition
New
CNC or Not
CNC
Place of Origin
China
Shandong
Brand Name
HONGKANG
Voltage
380V
Dimension(L*W*H)
4800*5000*4800mm
Weight (T)
19T
Warranty
1 Year
Key Selling Points
High Productivity
Applicable Industries
Manufacturing Plant, Energy & Mining, Other
Showroom Location
None
Product name
Boring Machine Tool
After-sales Service Provided
One Year
Packing & Delivery
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 6
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 7
Container
Company Profile
Shandong Hongkang Machinery Manufacturing Co., Ltd. is a manufacturer and exporter of machinery and equipment integrating R&D design, manufacturing and sales service, located at the western foot of the famous Mount Tai, founded in 1998.The leading products are CNC sheet uncoiling, leveling and shearing production line, CNC gold cutting machine tool, frequency conversion motor, planetary gear reducer and crane. The company has strong production, processing and manufacturing capabilities, with various types of advanced, professional processing and testing equipment to ensure processing quality and delivery time to meet customer needs.The company pays attention to the introduction, training and use of talents, and the proportion of engineering and technical personnel with middle and senior titles and skilled workers increases year by year. The company is a national high-tech enterprise with six provincial innovation platforms such as Shandong Provincial Enterprise Technology Center and Shandong Industrial Design Center, and more than 100 national invention and utility model patents. Successively passed three management system certifications of quality (ISO9001), environment (ISO14001) and occupational health and safety (ISO45001) and CE certification. Responsible for the development of 17 national and industry standards of leading products.
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 8
Our exhibition
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 9
SALES AND SERVICE NETWORK
19 T Weight TK6513 Floor Type Table Type Boring Machine for Heavy-Duty Applications 10
FAQ
1. who are we?
We are based in Shandong, China, start from 1998,sell to Domestic Market(70.00%),South Asia(5.00%),Eastern Asia(5.00%),South America(5.00%),Africa(5.00%),Eastern Europe(5.00%),Southeast Asia(5.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Plate Uncoiling, Leveling And Shearing Production Line, CNC Boring And Milling Machine, CNC Metal Plate Leveler, Mobile Sheet Metal Shears, Sheet Metal Slitting Machine

4. why should you buy from us not from other suppliers?
We have more than 20 years of design and R&D experience, strong production, processing and manufacturing capabilities, various advanced and professional processing and testing equipment, and rich after-sales experience.

5. what services can we provide?
Accepted Delivery Terms: null；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
