Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness

Certification
China Shandong Hongkang Machinery Manufacturing Co., Ltd. certification
I'm Online Chat Now

Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness

Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness

Large Image :  Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness

Product Details:
Place of Origin: Shandong, China
Brand Name: hongkang
Payment & Shipping Terms:
Minimum Order Quantity: A production line
Price: $90,000.00/sets 1-1 sets
Packaging Details: Container
Delivery Time: 1 line for 3 months
Payment Terms: L/C TT
Supply Ability: 1 line for 3 months

Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness

Description
Cutting Width (mm): 2000 - 12000 Mm Material Thickness(mm): 12 - 25 Mm
Cutting Speed(m/min): 15 - 30 M/min Video Outgoing-inspection: Provided
Machinery Test Report: Not Available Marketing Type: New Product 2023
Warranty Of Core Components: 1 Year Core Components: PLC, Bearing, Gearbox, Motor, Gear, Pump
Coil Weight (T): 35 Leveling Precision(±mm/m): 1.0 ±mm/m
Condition: New Voltage: 380V
Rated Power: 737kw Dimension(L*W*H): 56000*15000*1100
Weight: 20 Key Selling Points: Long Service Life
Warranty: 1 Year Applicable Industries: Energy & Mining, Other, Manufacturing Plant, Home Appliance Manufacturing, Automobile Manufacturing, Steel Mill, Steel Structure
Showroom Location: None Port: Qingdao Port

Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 0
Product Description
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 1
VR
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 2
Specification
application
Hot rolled steel coil
Thickness of coiled plate
12-25mm
W idth of coiled plate
2000mm
Cutting length
2000-12000mm
Line speed
15-30m/min
Loading capacity
≤35T
Coil I.D
Φ610/Φ760mm
Coil O.D
Φ1200/Φ2200mm
Length accuracy
± 1mm
Levelling accuracy
± 1mm
Direction of feed material
from Right to Left or Left to Right(customized
aggregate capacity
737KW
area covered
56000×15000×1100mm
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 3
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 4
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 5
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 6
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 7
Packing & Delivery
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 8
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 9
Container
Company Profile
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 10
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 11
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 12
Leveling and Cross Cutting Line for Hot Rolled Steel Coil 10-25mm Material Thickness 13
Shandong Hongkang Machinery Manufacturing Co., Ltd. is a manufacturer and exporter of machinery and equipment integrating R&D design, manufacturing and sales service, located at the western foot of the famous Mount Tai, founded in 1998.The leading products are CNC sheet uncoiling, leveling and shearing production line, CNC gold cutting machine tool, frequency conversion motor, planetary gear reducer and crane. The company has strong production, processing and manufacturing capabilities, with various types of advanced, professional processing and testing equipment to ensure processing quality and delivery time to meet customer needs.The company pays attention to the introduction, training and use of talents, and the proportion of engineering and technical personnel with middle and senior titles and skilled workers increases year by year. The company is a national high-tech enterprise with six provincial innovation platforms such as Shandong Provincial Enterprise Technology Center and Shandong Industrial Design Center, and more than 100 national invention and utility model patents. Successively passed three management system certifications of quality (ISO9001), environment (ISO14001) and occupational health and safety (ISO45001) and CE certification. Responsible for the development of 17 national and industry standards of leading products.
FAQ
1. who are we?
We are based in Shandong, China, start from 1998,sell to Domestic Market(70.00%),South Asia(5.00%),Eastern Asia(5.00%),South America(5.00%),Africa(5.00%),Eastern Europe(5.00%),Southeast Asia(5.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Plate Uncoiling, Leveling And Shearing Production Line, CNC Boring And Milling Machine, CNC Metal Plate Leveler, Mobile Sheet Metal Shears, Sheet Metal Slitting Machine

4. why should you buy from us not from other suppliers?
We have more than 20 years of design and R&D experience, strong production, processing and manufacturing capabilities, various advanced and professional processing and testing equipment, and rich after-sales experience.

5. what services can we provide?
Accepted Delivery Terms: null;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
