Product Details:
|
Cutting Width (mm): | 2000 - 12000 Mm | Material Thickness(mm): | 3 - 12 Mm |
---|---|---|---|
Cutting Speed(m/min): | 30 - 60 M/min | Video Outgoing-inspection: | Provided |
Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
Warranty Of Core Components: | 1 Year | Core Components: | Bearing, Motor |
Coil Weight (T): | 35 | Leveling Precision(±mm/m): | 1 ±mm/m |
Condition: | New | Rated Power: | 681KW |
Dimension(L*W*H): | 101500*13225*1100mm | Weight: | 277 |
Key Selling Points: | Automatic | Warranty: | 1 Year |
Applicable Industries: | Farms, Construction Works , Other, Building Material Shops, Machinery Repair Shops, Manufacturing Plant | Showroom Location: | None |
Port: | Qingdao Port |
application | Hot rolled steel coil |
Thickness of coiled plate | 12-25mm |
W idth of coiled plate | 2000mm |
Cutting length | 2000-12000mm |
Line speed | 15-30m/min |
Loading capacity | ≤35T |
Coil I.D | Φ610/Φ760mm |
Coil O.D | Φ1200/Φ2200mm |
Length accuracy | ± 1mm |
Levelling accuracy | ± 1mm |
Direction of feed material | from Right to Left or Left to Right(customized |
aggregate capacity | 737KW |
area covered | 56000×15000×1100mm |
